ESWIN WAN IoT ICs are SoCs designed for cellular IoT ( Internet of Things) and IoV (Internet of Vehicles) scenarios. Built with self-developed RISC-V processor architecture, the products integrate 4G/5G communication baseband, RF, power management modules, and protocol stacks. WAN IoT ICs can be applied to a broad range of fields, such as financial payments (POS/Cloud Speaker), shared devices, asset tracking, electricity, industrial internet, smart wearables, and industry-specific networks, featuring high stability and reliability, low power consumption, and high performance of WAN IoT experiences.


WAN IoT ICs
Product List
Application Scenarios Product Categories Product Models Product Specification
Processors Protocols Memory Security Mechanism Security Mechanism Functions Interfaces Operating Temperature (℃) Packaging (mm) Specs
data transmission (transparent POS/IPC, etc.) LTE Cat.1 SoC ECM9100‐A RISC-V E315 491.52 MHz 3GPP R15 Cat.1 & Cat.1 bis 2 MB SiP Nor Flash,support for plug-in Flash,4 MB PSRAM, 32 KB SRAM, 1Kbits OTP Secure Boot,AES, RSA, TRNG, OTP DCDC / LDO format: support TDD & FDD; bandwidth: 1.4/3/5/10/15/20 MHz; speed rate: max DL 10Mbps /UL 5Mbps GPIO / USB / UART / SPI / I²C / I²S / ADC -40 ~ 85 FCCSP BGA139, 6.2 mm * 5.8 mm
Open CPU (Open POS / cloud speaker / locator) LTE Cat.1 SoC ECM9100‐P RISC-V E315 491.52 MHz 3GPP R15 Cat.1 & Cat.1 bis 4 MB SiP Nor Flash,support for plug-in eMMC, 8 MB PSRAM, 32 KB SRAM, 1Kbits OTP Secure Boot,AES, RSA, TRNG, OTP DCDC / LDO format: support TDD & FDD; bandwidth: 1.4/3/5/10/15/20 MHz; speed rate: max DL 10Mbps /UL 5Mbps GPIO / USB / SDIO / UART / SPI / I²C / I²S / ADC / Keypad -40 ~ 85 FCCSP BGA195, 7.4 mm * 6.8 mm
