Intelligent Computing
Intelligent Computing SoCs
Intelligent Computing SoCs

Built with 64-bit out-of-order RISC-V processors and self-developed high-efficient NPUs, ESWIN Intelligent Computing SoCs support video encoding and decoding standards such as H.264 and H.265, and a rich set of audio and video interfaces. The chip computing power can reach up to 39.9TOPS. The ICs support full stack floating-point computation, comprehensively accelerate generative large models, and effectively break through the application challenges in industries such as AI PC and industrial vision. We provide various products forms such as chips, development boards and edge computing stations according to customers needs, and providing customers with high-efficiency smart computing solutions in the fields of large language models, speech synthesis, image/video generation, text generation, etc.


Intelligent Computing SoCs
Product List
Select Application Scenarios Product Categories Product Models Product Specification
Processors Computing Power Storage Audio and Video Coding Technologies Image Processing Functions Software Systems Interfaces Operating Temperature (℃) Packaging (mm) Specs
industrial appliances Edge Computing SoCs EIC7700 RISC-V RV64GC 4 cores@1.4Ghz 13.3 Tops Up to 32GB 64bit LPDDR4 / 4x / 5
eMMc 5.1
2 × SDIO 3.0
SATA3
SPI NOR Flash
• Supports HEVC ( H.265 ) and AVC ( H.264 ) encoding and decoding
• Decoding : H.265 up to 8K @ 50fps or 32 × 1080P @ 30fps
• Encoding : H.265 up to 8K @ 25fps or 13 × 1080P @ 30fps
JPEG ISO / IEC 10918 - 1、ITU - T T.81 M.2 Key Card mode :
• Linux ubuntu 18.04
• Linux CentOS 7.4

SoC mode :
• Embedded Linux ( Kernel 5.17 / 6.6 ) + SDK
• PCI - Express Gen3 4 × Lanes. Dual modes ( RC + EP )
• 2 × USB 3.0 with DRD ( Host + Device ),compatible with USB2.0
• 2 × GMAC, RGMII supported
-20 ~ 105°C FC - CSP(17 * 17) / FC - BGA (23 * 23)
industrial appliances Edge Computing SoCs EIC7700X RISC-V RV64GC 4 cores@1.4Ghz, up to 1.8GHz 19.95 Tops Up to 32GB 64bit LPDDR4 / 4x / 5
eMMc 5.1
2 × SDIO 3.0
SATA3
SPI NOR Flash
• Supports HEVC ( H.265 ) and AVC ( H.264 ) encoding and decoding
• Decoding : H.265 up to 8K @ 50fps or 32 × 1080P @ 30fps
• Encoding : H.265 up to 8K @ 25fps or 13 × 1080P @ 30fps
JPEG ISO/IEC 10918-1、ITU-T T.81 M.2 Key Card mode :
• Linux ubuntu 18.04
• Linux CentOS 7.4

SoC mode :
• Embedded Linux ( Kernel 5.17 / 6.6 ) + SDK
• PCI - Express Gen3 4 × Lanes. Dual modes ( RC + EP )
• 2 × USB 3.0 with DRD ( Host + Device ),compatible with USB2.0
• 2 × GMAC,RGMII supported
-20~105°C FC-CSP(17*17)/ FC-BGA (23*23)
industrial appliances AI PC ICs EIC7702 RISC-V RV64GC 8 cores @ 1.4Ghz 26.6 Tops Up to 64GB 128bit LPDDR4 / 4 × / 5
2 × eMMc 5.1
2 × SDIO 3.0
2 × SATA3
2 × SPI NOR Flash
• Supports HEVC ( H.265 ) and AVC ( H.264 ) encoding and decoding
• Decoding : H.265 up to 8K @ 100fps or 64 × 1080P @ 30fps
• Encoding : H.265 up to 8K @ 50fps or 26 × 1080P @ 30fps
JPEG ISO / IEC 10918 - 1、ITU - T T.81 M.2 Key Card mode :
• Linux ubuntu 18.04
• Linux CentOS 7.4

SoC mode :
• Embedded Linux ( Kernel 5.17 / 6.6 ) + SDK
• 2 × PCI - Express Gen 3 4 × Lanes. Dual modes ( RC + EP )
• 4 × USB 3.0 with DRD ( Host + Device ),compatible with USB2.0
• 4 × GMAC, RGMII supported
-20 ~ 105°C FC - BGA (35 * 35)
industrial appliances AI PC ICs EIC7702X RISC-V RV64GC 8 cores@1.4Ghz, up to 1.8GHz 39.9 Tops Up to 64GB 128bit LPDDR4 / 4 × / 5
2 × eMMc 5.1
2 × SDIO 3.0
2 × SATA3
2 × SPI NOR Flash
• Supports HEVC ( H.265 ) and AVC ( H.264 ) encoding and decoding
• Decoding : H.265 up to 8K @ 100fps or 64 × 1080P @ 30fps
• Encoding : H.265 up to 8K @ 50fps or 26 × 1080P @ 30fps
JPEG ISO / IEC 10918 - 1、ITU - T T.81 M.2 Key Card mode :
• Linux ubuntu 18.04
• Linux CentOS 7.4

SoC mode :
• Embedded Linux ( Kernel 5.17 / 6.6 ) + SDK
• 2 × PCI - Express Gen 3 4 × Lanes. Dual modes ( RC + EP )
• 4 × USB 3.0 with DRD ( Host + Device ),compatible with USB2.0
• 4 × GMAC,RGMII supported
-20~105°C FC-BGA (35*35)
