ESWIN Intelligent Terminal Power ICs mainly provides OLED multi-channel integrated power solutions with ultra-low power consumption, high efficiency, and low noise. The products can be widely used in intelligent terminal products such as notebooks, tablets, mobiles, and smart wearables.
| Product List | ||||||||||
| Select | Application Scenarios | Product Categories | Product Models | Product Specification | ||||||
| Basic Modules | Vin(Min~Max)(V) | Vout(Min~Max)(V) | Iout(Max)(A) | Operating Temperature (℃) | Packaging (mm) | Specs | ||||
| mobiles | OLED PMICs | EPC9905 | ELVDD / ELVSS / AVDD | 2.9 ~ 5 | 4.6 - 6.6 ~ -1 6.9 ~ 7.9 |
0.65 | UVLO / SCP / OLP / OTP | WLCSP - 25B ( 2.07 * 2.07 ) | ||
| wearable devices | OLED PMICs | EPC9988 | OVDD / OVSS / AVDD | 2.9 ~ 5.5 | 2.8 ~ 4.0 -4.5 ~ -0.6 2.8 ~ 3.6 |
0.08 | UVLO / OCP / UVP / OTP | WLCSP - 18B ( 2.50 * 1.29 ) | ||
| wearable devices | OLED PMICs | EPC9910 | OVDD / OVSS / AVDD | 2.9 ~ 5.5 | 2.8 ~ 4.0 -4.5 ~ -0.6 2.8 ~ 3.6 |
0.08 | UVLO / OCP / UVP / OTP | WLCSP - 18B ( 2.50 * 1.29 ) | ||
Please check the circle on the left side of the table and select the document you need to download
